Sinotruk Haoman H5 cleaning truck

  • KLF
  • Suizhou,Hubei
  • According to order requirements
  • 100pcs/month
Powerful cleaning system: equipped with advanced cleaning brushes and vacuum devices, it can quickly and effectively clean various types of garbage, including dust, paper scraps, leaves, small stones, etc. The cleaning brush is made of high-quality materials that are wear-resistant and not easily deformed, ensuring the cleaning effect and service life.

Medium Road Sweeper Truck for City Street


Product Parameters:

Specific parameters

Basic Information
Drive type:
4X2
Wheelbase:
5000mm
type:
Washing and sweeping car
Body size:
8.6×2.5×3.06 m
Total mass:
16 tons
Rated quality:
4.25 tons
Front track/rear track:
Front track: 2020mm; rear track: 1860mm
Front overhang/rear overhang:
1.32/2.28m
Engine parameters
Engine Model:
Sinotruk MC05.21-50
Displacement:
4.58L
Maximum output power:
151kW
Maximum horsepower:
210 HP
Emission standards:
National Five
Fuel Type:
diesel fuel
Rated speed:
2400rpm
Upload parameters
Vehicle announcement:
ZZ5168TXSG10EB0
Top brand:
Sinotruk Homan
Cab parameters
Cab:
H5 half-height top
Gearbox parameters
Gearbox Model:
Sinotruk HW12710C
Number of gears:
10 levels
Chassis parameters
Chassis Brand:
Sinotruk Homan
Chassis series:
Hauman H5
Chassis Model:
ZZ1168G10EB0
Rear Axle Description:
153 rear axle, optional 457
Number of springs:
11/9+8
Frame size:
250×80×(7+4)×865mm
Tire
Number of tires:
6
Tire specifications:
9.00R20,10.00-20,10.00R20
Welcome to inquiry!


Product Advantage:

  • Efficient cleaning capability

    Wide width cleaning operation, with a cleaning width of up to 2.5-3 meters, can cover a large area of road surface, reducing cleaning time and operation frequency. At the same time, the cleaning vehicle can adjust the cleaning width according to actual road conditions and operational needs, flexibly adapting to the cleaning requirements of different streets. The integrated design of suction and sweeping ensures that garbage is collected in a timely manner during the cleaning process, avoiding secondary dust. The vacuum system has high suction power and can suck garbage into the garbage bin, ensuring a clean and tidy road surface after cleaning.

  • Good adaptability to homework

    Flexible cleaning modes, with multiple cleaning modes such as full sweeping, half sweeping, sweeping suction, etc., can be selected according to different road conditions and cleaning needs. For example, in narrow streets or areas with high traffic flow, a half scan mode can be used to reduce the impact on traffic; In areas with a lot of dust, the scanning and suction mode can be used to improve the cleaning effect.

  • Convenience of operation

    Humanized operation interface: The cab is equipped with an operation panel, which is easy to operate and understand. Drivers can control various functions of the sweeper through the control panel, such as sweeping, vacuuming, spraying water, etc. At the same time, the vehicle is also equipped with a display screen, which displays the work status and related parameters in real time.

  • Security performance

    Safety protection devices: The vehicle is equipped with various safety protection devices, such as reverse radar, warning lights, rearview mirrors, etc., to ensure the safety of the driver during the operation process. At the same time, the vehicle also has an emergency braking function, which can stop in a timely manner in case of an emergency. Stable driving performance, the chassis design of the medium-sized road sweeper is reasonable, with good stability and handling. The vehicle can maintain stability during driving and avoid accidents such as rollover.


Company Strength:

Road Sweeper Truck

Medium Road Sweeper Truck

Customer photos:

road sweeper price

  • Where is your factory located?

    We are located in Suizhou City,Hubei Province,China

  • How can i visit there?

    Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.

  • Could you customize exactly according to my requirements?

    Yes. We have professional R&D team, we can produce the product exactly according to your requirements.

  • Do you provide certification that we need?

    We can provide various certifications associate. Such as ISO9000, CCC,SGS, TUV, E-Mark, EU.

  • what's your payment terms?

    T/T& L/C are preferred.
