Refrigerated truckt Configurations
Chassis & Powertrain
Engine: JL473QH gasoline engine, 1.5L displacement, delivering 78kW power output.
Emission Standard: Compliant with Euro III regulations.
Transmission: 5-speed manual transmission with smooth gear shifting.
Drivetrain: Rear-wheel drive for enhanced load capacity and stability.
Fuel Tank Capacity: 40L, optimized for long-haul operations.
Suspension: Front MacPherson independent suspension + rear leaf spring suspension.
Tires: 185R14LT high-strength steel-belted radial tires.
Axle Load: 2,600mm wheelbase for balanced maneuverability and cargo space.
Payload Capacity: 1,000kg (approx.).
Refrigerated Truck Cargo Body
Dimensions: 3m³ internal volume (customizable length/width/height options available).
Insulation: 50mm-thick polyurethane foam insulation panels (thermal conductivity ≤0.035W/m²K) for superior temperature retention.
Material: Fiberglass-reinforced plastic (FRP) exterior + stainless steel inner lining, ensuring corrosion resistance and hygiene.
Door Configuration: Rear double doors with integrated seals; optional side doors for versatile loading.
Flooring: Anti-slip aluminum alloy floor with drainage design.
RefrigerationTruck System
Cooling Unit: Branded direct-drive refrigeration system (e.g., Carrier or equivalent), capable of maintaining temperatures from -10°C to +20°C (±2°C precision).
Cooling Capacity: 2,000W, suitable for tropical and sub-zero climates.
Power Supply: 12V DC powered by vehicle battery + optional standby power backup.
Control Panel: Digital temperature display with adjustable settings and alarm functions for temperature deviations.
Refrigerated truck Additional Features
Hydraulic Power Steering: Ensures effortless handling in urban environments.
Safety: ABS braking system, reinforced rear bumper, and fire-resistant wiring.
Comfort: Air-conditioned cabin, ergonomic driver’s seat, and user-friendly dashboard layout.
Customization: Optional upgrades include GPS tracking, LED interior lighting, and telematics for fleet management.
Refrigerated truck Operational Advantages
Cost-Effective: Low fuel consumption and maintenance costs.
Adaptability: Ideal for short-to-medium distance cold chain logistics in both urban and rural areas.
Compliance: Meets international standards for emissions and food safety (HACCP-ready design).
Target Markets
Export-focused regions with Euro III acceptance, including Southeast Asia, Africa, and the Middle East.
Note: Specifications may vary based on regional requirements. Contact our sales team for tailored configurations and aftersales support.
